NFP installation
NFP25C

NFP 25
NORTwood Fluted Panel

12 Feet Panel: 26x193mm x3650mm
 (1″x 8 1/2″ x 144″) ||  8.4 Sq.ft

9 Feet Panel: 26x193mm x2880mm
 (1″x 7-1/2″ x 113″) ||  5.88 Sq.ft

2.3 Kg/m  || 1.5 lbs
Box weight:  24.5kg  || 54 lbs

Nortwood Flouted Panel
NFP40_png

NFP 40

NORTwood Fluted Panel

12 Feet Panel: 26x208mm x3650mm
 (1″x 8 1/2″ x 144″) || 8.4 Sq.ft

9 Feet Panel: 26x208mm x2880mm
(1″x 8 1/2″ x 113″)  || 6.67 Sq.ft

2.2 Kg/m  || 1.33 Lbs
Box weight: 23.8 Kg ||
52.5 lbs

Nortwood Flouted Panel

NWP

NORTwood Wall Panel

18x160mm x3600mm
(5/7″x 6″ x 142″)   | 6 Sq.Ft

2 kg/m || 1.33 lbs
Box weight:  29 Kg || 64 lbs

Nortwood Wall Panel
Wall Panel

LUV 100

Louver Panel

50x100mm x3600mm
(2″x 4″ x 144″)

2.5 Kg/m || 1.67 lbs

Box weight: 27.7 Kg || 61 lbs

Material

60% Sawdust + 40% HDPE

Thermal Conductivity

0.19738W/ m.k(CE EN14041)

Moisture Content

0.4% (EN322)

Discoloration

8% Exhibition after 20000 hr



Brinell Hardness

8.2N/mm2(EN15534)

Expansion

44.2×10.6 K-1 (ISO 11359-2)

CAD & PDF

Download the details for your next project.

For CAD details, please contact us at email:  info@nortwood.com
